VTrack Retractable Golf Simulator Bundle - SportsScreen Vanish

Pro-Level Overhead Tracking. A Simulator That Disappears. Your Garage Back in 5 Minutes.

The VTrack Golf Simulator Bundle — Vanish Series solves the problem every multi-purpose space faces: how to have a serious simulator without giving up your room permanently. The SportsScreen Vanish Series is the world's first retractable golf simulator enclosure — ceiling-mounted, roll-up, and fully stowed in under 5 minutes. The VTrack DX10 is a ceiling-mounted overhead launch monitor with no floor unit, no stickers, and no marked balls required.

Together, they create something no fixed-enclosure bundle can: a complete, professional simulator that leaves no trace when you're done. VTrack stays mounted to the ceiling. The Vanish screen rolls up. You drive your car in, host your party, or use your space for anything else — then drop the screen, tee it up, and play 18 holes. No disassembly. No storage problem. No compromise.

Select your Vanish model and retraction style at checkout. Five standard sizes available — from the compact Vanish 9 to the wide-format Vanish 16H — plus custom configurations. VTrack connects via USB, the enclosure mounts via included hardware, and both live on the ceiling out of the way until you need them.

Key Benefits

• ✔ A Simulator That Completely Disappears
  The Vanish enclosure — impact screen, side panels, ceiling panel, everything — rolls up to the ceiling in under 5 minutes. VTrack stays mounted overhead. Your floor is completely clear. No other bundle in this lineup offers this.
• ✔ Overhead Tracking — No Floor Unit, Nothing to Move
  Because VTrack is ceiling-mounted, there's no floor unit to relocate when you retract the enclosure. The only thing you're moving when you're done is your hitting mat. The entire simulator system lives above your head when not in use.
• ✔ No Stickers, No Marked Balls, No Setup Prep
  VTrack's dual 1,800 FPS cameras capture full ball and club data with any standard golf ball. No reflective dots, no club-face stickers, no proprietary equipment. Drop a ball and swing.
• ✔ Largest Hitting Zone in Its Class — 31" × 24"
  No repositioning for your stance. No worrying about missing the detection area. Left- and right-handed players alternate without any adjustment to the launch monitor.
• ✔ Fully Retractable in Under 5 Minutes
  Hand crank or motorized remote — your choice. The motorized version works with Alexa, Google Home, and Tuya for voice-controlled deployment and retraction. Say the word and your simulator appears.
• ✔ Complete Enclosure Coverage When Deployed
  This isn't just a retractable screen. It's a full enclosure with 5-foot side panels, ceiling protection, corner pieces, front and side baffles, and a blackout support membrane. Mishits stay contained. Your walls and ceiling stay safe.
• ✔ Premium 3-Ply Impact Screen + Blackout Backing
  Triple-layer impact screen with a rear blackout support membrane for improved projection clarity, extended screen life, reduced bounce-back, and quieter operation.
• ✔ Five Size Options + Custom Configurations
  From the compact Vanish 9 (1:1 ratio) to the wide Vanish 16H (16:9 tall) — five standard sizes cover virtually every room configuration. Custom sizes available for non-standard spaces, plus 2-foot height extensions for taller ceilings.
• ✔ Multi-Purpose Entertainment
  Movie nights, sports viewing, VR gaming, workouts — the Vanish doubles as a massive home theater screen when deployed. When retracted, you have your full room back.
• ✔ Lifetime Frame Warranty + 2-Year Component Coverage
  Lightweight aluminum frame backed by a lifetime warranty. All other components — screens, panels, motor — covered for 2 years.
• ✔ Ultra-Fast Feedback — 200–250ms
  VTrack shot data appears virtually instantly after impact. No perceptible delay between swing and ball flight on screen.
• ✔ Native GSPro Integration — No Connector Fee
  VTrack connects to GSPro natively, saving approximately $250 per year versus systems that require a third-party connector.
• ✔ No Subscription Fees for the Hardware
  VTrack ToolKit and VTrack Practice Range ship with lifetime licenses. No annual fee to run the launch monitor.

Who Is This For?

• ✅ Garage simulator builders who still need to park their cars
• ✅ Multi-purpose rooms that can't be dedicated solely to golf
• ✅ Homeowners who want a serious simulator without a permanent structure
• ✅ Smart home enthusiasts who want voice-controlled deployment via Alexa or Google Home
• ✅ Those who want a clean aesthetic — no enclosure visible when not in use
• ✅ Renters or anyone who needs a non-permanent, reversible solution
• ✅ Lefty/righty households — VTrack handles both natively with no adjustment
• ✅ GSPro users who want native overhead integration without connector fees
• ✅ Families who need the space for more than just golf

How VTrack and the Vanish Work Together

Most simulator bundles face a storage problem when combined with a retractable enclosure — you still have a floor unit, a mat, and cables to deal with. This bundle is different:

• VTrack mounts permanently to the ceiling — connected via a single USB cable routed to your PC. It stays up regardless of whether the enclosure is deployed or retracted.
• The Vanish enclosure rolls up around it — the VTrack's compact form factor (12.5" H × 6.5" W × 4.5" D) sits comfortably on the ceiling alongside the retracted Vanish canister when stowed.
• When you want to play — drop the Vanish screen (crank or remote), slide out your hitting mat, and you're hitting balls. No repositioning the launch monitor. No reconnecting cables.
• When you're done — roll the Vanish back up, slide the hitting mat to the side or store it, and your space is completely clear. The VTrack stays on the ceiling, ready for next time.

Ceiling Layout Planning: The VTrack mounts 36–42" in front of the ball position, 8.5–10' above the hitting surface. Plan your ceiling layout so the VTrack and the Vanish mounting rail both have adequate clearance. Given the Vanish rail runs along the top of the screen, and VTrack sits forward of the screen, the two systems typically coexist without conflict. Contact us at (770) 766-5571 if you'd like help confirming your ceiling layout before ordering.

Choose Your Vanish Model

Five standard sizes are available, each designed for a specific room width and aspect ratio. Select your model at checkout based on your room dimensions and projection preference.

Not sure which size is right for your room? Call or text us at (770) 766-5571 and we'll help you confirm the best Vanish model for your space before you order.

Retraction Options — Hand Crank or Remote Control

Both retraction options deploy and stow the complete enclosure in under 5 minutes. The motorized version is faster and hands-free; the hand crank version is reliable and requires no electrical access at the mounting location.

What's in This Bundle

VTrack DX10 — What's Measured

Technical Specifications

VTrack DX10 Launch Monitor

SportsScreen Vanish Series Enclosure

PC Requirements (for VTrack)

Software & Simulator Compatibility

Included with VTrack (Lifetime License — No Annual Fee):

• VTrack ToolKit — Ball flight analysis, club delivery data, impact location, CSV export
• VTrack Practice Range — Structured practice sessions and driving range mode

Third-Party Simulator Compatibility:

• GSPro — Native integration, no connector fee
• E6 Connect
• E6 Apex
• TGC 2019

Third-party software requires its own separate license. VTrack does not charge additional fees to enable connectivity.

Projector Options

Select your projector at checkout, or choose "No Projector" if you already own one. The Vanish screen is designed for each specific aspect ratio — match your projector output to your chosen Vanish model for best results:

• Vanish 9 (1:1): Any short-throw projector — slight letterboxing with 16:9 output above and below, similar to the SIG8
• Vanish 11 / 13H (4:3): Standard projector output fills the screen fully — no letterboxing
• Vanish 16 / 16H (16:9): Standard 16:9 projector output fills the screen fully — the most cinematic format, and ideal if you also use the Vanish as a home theater

What's Included

• VTrack DX10 Launch Monitor
• Ceiling Mounting Bracket & Hardware
• USB 3.0 Cable
• Power Cable & Adapter
• VTrack ToolKit Software (Lifetime License)
• VTrack Practice Range Software (Lifetime License)
• SportsScreen Vanish Series Enclosure — your choice of model
• Premium 3-Ply Impact Screen
• Rear Impact Support Membrane / Blackout Screen
• 2× Side Screens (5-foot depth)
• Ceiling Panel
• 2× Corner Pieces
• 2× Side Baffles + 1× Front Baffle
• Wall/Ceiling Mounting Brackets + Assembly Hardware
• Hand Crank or Remote Control Motor (based on variant selected)
• Optional Projector (if selected at checkout)

What's NOT Included

• Hitting mat (not included with the Vanish — add your preferred mat separately)
• Projector (unless selected at checkout)
• Projector mount and cables
• Computer / PC for running simulator software
• Simulator software — GSPro ($250/yr), E6 Connect, etc. sold separately

Hitting Mat Note: Unlike the SIG Series bundles, the Vanish enclosure does not include a hitting mat. We recommend adding the SIGPRO Softy 4'×7' for this setup — it's easy to slide out of the way when retracting the enclosure, and its foam backing won't scratch garage floors. Contact us to add a mat to your order.

Space & Installation Requirements

Installation Overview

VTrack Installation (Under 30 Minutes):

1. Mount the ceiling bracket 36–42" in front of ball position, 8.5–10' above hitting surface
2. Attach VTrack unit to bracket and connect USB 3.0 cable to PC
3. Install VTrack software and run the 2-step auto-calibration
4. Start hitting

Vanish Series Installation (Two People Recommended):

1. Plan ceiling layout — confirm VTrack bracket position and Vanish rail position are compatible
2. Mount the Vanish ceiling/wall brackets using included hardware
3. Attach the Vanish canister (with enclosure rolled inside) to the brackets
4. Connect power for motorized version (or confirm hand crank operation)
5. Attach side panels, baffles, and corner pieces per installation guide
6. Deploy the enclosure and check alignment — adjust if needed
7. Test retraction cycle before first use

Both systems can be installed in the same session. Plan your ceiling layout first, install VTrack, then install the Vanish rail adjacent to it.

Shipping & Returns

Shipping: Ships in 7–10 business days. Free shipping within the contiguous United States.

Returns: 30-day hassle-free return policy. Customer responsible for return shipping costs. A 15% restocking fee applies.

Frequently Asked Questions

How does VTrack work with a retractable enclosure?
VTrack mounts permanently to the ceiling — it stays up regardless of whether the Vanish is deployed or retracted. When you want to play, drop the screen and slide out your mat. When you're done, roll the screen up and move the mat. VTrack stays mounted and ready. There's no floor unit to move or reconnect between sessions.

Does VTrack require club stickers or special balls?
No. VTrack uses markerless tracking with any standard golf ball. No stickers, no marked balls, no proprietary equipment required.

Which Vanish model is right for my space?
The minimum room depth is 17' (204") for all models. Room width determines your model: compact spaces → Vanish 9; standard garages → Vanish 11; taller rooms → Vanish 13H; wide spaces → Vanish 16 or 16H. Contact us at (770) 766-5571 and we'll confirm the right model for your exact room dimensions.

What ceiling height does the Vanish need?
Standard Vanish models work with ceiling heights from 62" to 115". 2-foot height extensions are available for taller ceilings. VTrack mounts 8.5–10' above the hitting surface — confirm this aligns with your ceiling height before ordering.

Will VTrack and the Vanish mounting rail fit on the same ceiling?
In most configurations, yes. VTrack's compact form (12.5" H × 6.5" W × 4.5" D) sits 36–42" in front of the screen, which is where the VTrack bracket lives. The Vanish rail sits at the top of the screen opening. These are different ceiling positions and typically don't conflict. Contact us if you'd like to talk through your specific ceiling before ordering.

Hand crank vs. remote control — which should I choose?
If you have a 110V outlet at the mounting location (or can add one), the remote control version is more convenient — especially with smart home integration. If power access is difficult or you prefer simplicity, the hand crank is reliable and requires nothing but the included tool. Both fully retract the enclosure in under 5 minutes.

Does the Vanish work with a 4K projector?
Yes. The 3-ply impact screen delivers excellent image quality for both HD and 4K projection. 4K is most visibly impactful on the larger Vanish 13H, 16, and 16H models.

Is a hitting mat included?
No — unlike the SIG Studio bundles, the Vanish enclosure does not include a hitting mat. We recommend the SIGPRO Softy 4'×7' for this setup as it's easy to slide aside when retracting the enclosure. Contact us to add a mat to your order.

What simulator software can I use with VTrack?
VTrack integrates natively with GSPro (no connector fee), E6 Connect, E6 Apex, and TGC 2019. VTrack ToolKit and Practice Range are included with lifetime licenses. Third-party software sold separately.

Can left- and right-handed players both use this?
Yes. VTrack supports both handednesses natively with no repositioning or recalibration. The Vanish enclosure accommodates both as well — no adjustment needed when switching players.

Can the Vanish be used for things other than golf?
Yes. The Vanish works as a home theater screen for movies, sports viewing, VR gaming, and workouts when deployed. Multi-sport attachments are also available. When retracted, your space is completely clear for any other use.

What is VTrack's warranty?
VTrack carries a 12-month warranty from Laon Swingcraft. The Vanish Series carries a lifetime warranty on the aluminum frame and 2 years on all other components. Contact Golf Sim Depot at (770) 766-5571 for warranty support on either component.

Can I use a Mac with VTrack?
No. VTrack requires Windows 10 or Windows 11. macOS is not currently supported.
